ABB 5SHY35L4503 / 5SXE01-0127 Series Thyristor (IGCT) Module Overview IGCT (Integrated Gate-Commutated Thyristor): Thermal Management: Communication & Integration: The ABB 5SHY35L4503 (including variants 3BHB004693R0001 and 3BHB004692R0002) and its compatible model 5SXE01-0127 are high-performance IGCT modules designed for high-voltage, high-current industrial power electronics applications. They feature fast switching speed, wide operating temperature range, and comprehensive protection capabilities, making them ideal for power transmission, industrial automation, and high-power DC drive systems.
Item
Main Parameters
Product Model
5SHY35L4503 (main model) / 3BHB004693R0001, 3BHB004692R0002 (corresponding part numbers) / 5SXE01-0127 (alternative / compatible model)
Electrical Characteristics
Rated voltage: 4500 V (max. withstand up to 6000 V) • Rated current: 350 A • Breaking capacity: ≥ 120 kA • Repetitive peak reverse voltage (VRRM): 4500 V • Average on-state current (IT(AV)): 350 A
Switching Performance
Switching speed ≈ 1 µs (fast response) • Gate trigger current ≤ 300 mA • Trigger voltage ≤ 3 V
Structure & Package
Disc-type (DO) package with stud-mount design • Approx. dimensions: 300 mm × 300 mm × 100 mm • Weight: about 10 kg
Operating Temperature Range
−40 °C to +150 °C
Main Application Areas
• Power transmission and distribution • Industrial automation and process control • Rail transportation, oil & gas, renewable energy systems • High-power DC drives and industrial power supplies
Key Advantages
• High voltage and current handling capability • Fast response with low gate trigger current • Advanced thermal design for long-term reliability • Integrated over-voltage, over-current, and over-temperature protection
Certifications & Quality
CE, UL international certifications; one-year manufacturer warranty
Spare Parts & Compatibility
Model 5SXE01-0127 is a compatible replacement within the same series and can be used as a direct substitute in existing systems
Key Technical Highlights
A type of asymmetric thyristor that enables precise current control and fast switching in high-power applications. It is well-suited for scenarios that demand high responsiveness and exceptional reliability.
The module features an optimized heatsink structure to maintain safe temperature levels during continuous high-power operation, improving both service life and operational reliability.
Certain versions are equipped with built-in Ethernet switches and Modbus/TCP support, allowing direct connection to SCADA and PLC systems for remote monitoring and parameter adjustment.
