🔧 Bently Nevada TK-3E 177313-02-02 Overview
Bently Nevada TK-3E (Part No. 177313-02-02) is a portable proximity system test kit designed for calibration, verification, and troubleshooting of machinery vibration and position monitoring systems.
It is widely used in industries such as oil & gas, power generation, petrochemical, and manufacturing.
⚙️ Key Features
- Portable calibration tool for proximity probe systems
- Simulates shaft vibration and position for accurate testing
- Supports 3300 / 3300 XL series proximity systems
- Dual testing modes:
- Calibration (micrometer-based)
- Vibration simulation (shaker-based)
- Built-in tachometer simulation (speed testing)
- Compatible with multiple probe sizes (5 mm to 50 mm)
🧪 Main Functions
1. Calibration
- Verifies probe linearity and sensitivity
- Adjusts gap voltage
- Ensures accurate displacement readings
2. Vibration Simulation
- Simulates real machine vibration conditions
- Frequency range: approx. 5 Hz to 2 kHz
3. System Verification
- Tests complete loop:
- Probe
- Extension cable
- Proximitor sensor
- Monitoring system
4. Tachometer Testing
- Simulates rotational speed signals for system validation
📊 Technical Specifications
- Model: TK-3E (Electric Driven)
- Part Number: 177313-02-02
- Scale Units: Metric (02)
- Power Cord: European type (02)
- Micrometer Range: up to 25 mil / 635 µm
- Vibration Range: up to ~500 µm p-p
- Power Supply: AC or internal battery (depending on configuration)
- Weight: approx. 4–8 kg
- Protection: IP54 enclosure
🧰 Typical Applications
- Commissioning of new monitoring systems
- Preventive maintenance & calibration
- Troubleshooting vibration alarms
- Machinery health diagnostics
- Training and lab simulation
✅ Advantages
- ✔ Eliminates need to remove probes during testing
- ✔ Improves measurement accuracy and system reliability
- ✔ Reduces downtime and maintenance costs
- ✔ Industry-standard tool for condition monitoring engineers
📌 Summary
The Bently TK-3E 177313-02-02 is an essential diagnostic and calibration instrument for ensuring the accuracy and reliability of proximity-based vibration monitoring systems. It is considered a standard tool in predictive maintenance programs for rotating machinery.
