EMERSON TPMC917
EMERSON TPMC917 Overview
The EMERSON TPMC917 is a high-reliability PMC (PCI Mezzanine Card) module designed for industrial control applications. It is commonly used with the Emerson MVME5500 single-board computer to provide embedded I/O and non-volatile storage functions.
Module Specifications
- Form Factor: Standard 32-bit, single-width PMC compliant with IEEE P1386.1
- Dimensions: Approx. 149 mm × 74 mm
- Interface: PCI 2.1, supporting both 3.3 V and 5 V signaling levels
Memory and Power
- Equipped with 4 MB (or 2 MB) non-volatile SRAM, backed up by a lithium battery
- Battery voltage is automatically monitored every 24 hours
- Interrupts can report battery voltage status to ensure data integrity after power loss
Serial Interfaces
- Provides four asynchronous RS-232 serial ports (model TPMC917-10R)
- Each port includes 64-byte transmit and 64-byte receive FIFOs
- Programmable baud rates up to 115.2 kbaud
- All serial channels feature ESD protection, making them suitable for electrically noisy industrial environments
Operating Environment and Reliability
- Operating temperature: 0 °C to +70 °C (extended versions: –40 °C to +85 °C)
- MTBF (Mean Time Between Failures): Between 346,000 h and 560,000 h, compliant with MIL-HDBK-217F/EN2 standards
Power and Dimensions
- Power supply: 24 V DC
- Physical characteristics: Approx. 500 g, 160 mm × 233 mm × 30 mm
Compatibility and Applications
- Seamlessly interfaces with Emerson MVME5500 VME-bus SBCs via PMC slots
- Compatible with major operating systems including VxWorks, Linux, Windows, and QNX
- Ideal for power generation, chemical processing, metallurgy, petrochemical, rail transit, defense, and medical imaging industries—applications demanding high real-time performance, noise immunity, and system reliability
Summary
The EMERSON TPMC917, featuring robust non-volatile memory, multiple RS-232 serial ports, and industrial-grade reliability, delivers dependable and expandable I/O and data-retention capabilities. When paired with Emerson’s MVME5500 platform, it serves as a key hardware component for achieving high-performance, real-time closed-loop control in demanding industrial environments.
