Product Overview

The GE 8751-CA-NS is a premium industrial control relay designed for demanding applications requiring high reliability and precise control. This versatile relay offers exceptional electrical characteristics and robust construction for industrial automation systems.

Technical Specifications

Parameter Specification
Model Number 8751-CA-NS
Manufacturer General Electric (GE)
Contact Configuration DPDT (Double Pole Double Throw)
Coil Voltage 24-240V AC/DC (depending on model variant)
Contact Rating 10A @ 240V AC / 12A @ 120V AC
Electrical Life 500,000 operations at rated load
Mechanical Life 10,000,000 operations
Operating Temperature -40°C to +70°C (-40°F to +158°F)
Insulation Resistance 100 MΩ minimum at 500V DC
Dielectric Strength 2000V AC for 1 minute
Mounting DIN rail or panel mount
Weight Approx. 150g
Compliance UL 508, CSA C22.2 No. 14, IEC 60947-4-1

Key Features

  • LED status indicator for visual operation confirmation
  • Transparent dust cover for contact inspection
  • Mechanical flag indicator for contact position
  • Test button for manual operation
  • Wide range of socket options available
  • High shock and vibration resistance
  • Universal coil voltage options

Applications

Industrial Automation

Machine control, conveyor systems, and assembly line automation

HVAC Systems

Heating, ventilation, and air conditioning control applications

Power Distribution

Control circuits in power distribution systems

Motor Control

Control and protection of AC/DC motors
