The GE IC695ALG508-AA is an analog input module manufactured by General Electric (GE) and is part of the PACSystems RX3i series. It is primarily used in industrial automation systems to receive signals from Resistance Temperature Detectors (RTDs).

Key Features:

Differential RTD Inputs: The IC695ALG508-AA provides 8 isolated differential RTD input channels, each with independent isolation, which effectively suppresses common-mode interference and improves measurement accuracy.

Supported RTD Types: This module supports a wide range of RTD types, including:

Pt 385, Pt 391.6, Ni 618, Ni 672, NiFe 541, Cu 426, as well as standard types like PT100 and PT1000.
Resistance range from 250 to 4000 ohms.

Temperature Measurement Range and Accuracy:

The temperature measurement range typically spans from -200°C to +850°C, depending on the selected RTD type.
The module offers a resolution of 16 bits, ensuring high-precision measurements.

Configuration and Flexibility:

The module is fully software-configurable, eliminating the need for jumper settings. Users can adjust the sampling rate, input range, and sampling type as needed.
It supports user scaling, programmable filters, range alarm detection, and fault reporting features.

Installation and Compatibility:

It supports various terminal block types, including box-style, extended box-style, spring-style, and extended spring-style.

Applications:

The IC695ALG508-AA is ideal for industrial automation, process control, and data acquisition systems.

Other Features:

The module includes self-diagnostic capabilities that can detect system faults and open circuits in sensors.
It supports hot swapping, allowing for the insertion or removal of the module while the system is powered on.

Conclusion:

The GE IC695ALG508-AA is a high-performance analog input module designed for accurate temperature measurement in industrial automation. It offers isolation, flexible configuration options, and a wide range of applications, making it suitable for use in demanding industrial environments.
