Technical Parameter

The GE IC697VDD100 is a VersaMax Dual DC Input Module used in GE Fanuc’s VersaMax and 90-30 Series PLC systems.

Key Specifications:

• Module Type: Dual DC Input Module (Sinking or Sourcing)
• Input Channels: 2 isolated DC inputs
• Input Voltage Range:
  • 5V DC: 4.5V – 5.5V
  • 24V DC: 19V – 30V
• Isolation: 1500V AC between field and logic side
• Response Time: Typically < 1ms
• Current Consumption: 5V DC (logic side) – 25mA max
• Compatibility:
  • VersaMax I/O (IC200, IC600 series racks)
  • Series 90-30 PLCs (with appropriate rack)

Wiring & Configuration:

• Terminal Block: Removable screw-type for easy wiring
• Input Types:
  • Sinking (NPN): Common +V, input pulls to ground
  • Sourcing (PNP): Common ground, input pulls to +V
• LED Indicators: Per-channel status (ON/OFF)

Applications:

• Industrial automation
• Machine control
• Process monitoring

Compatible Software:

• Proficy Machine Edition (PME)
• VersaPro (older systems)

Replacement & Legacy Status:

• Part of the VersaMax series, which is now under Emerson Automation (after GE’s industrial automation division was acquired).
• Check for modern alternatives like Emerson’s PACSystems if upgrading.
