Technical Parameter

The GE IS200TTURH1CCC (S1DF00Z) is a Turbine Temperature Control Module designed for GE’s Mark VI and Mark VIe turbine control systems.

General Specifications

• Manufacturer: GE (General Electric)
• Model: IS200TTURH1CCC
• Part Number: S1DF00Z (specific variant/revision)
• Series: Mark VI / Mark VIe
• Type: Turbine Temperature Control Module
• Function: Monitors and controls turbine exhaust/combustion temperatures for gas/steam turbines.

Hardware Specifications

1. Inputs & Signal Processing

• Temperature Inputs:
  • Thermocouples (Type K, J, E, etc.)
  • RTDs (Pt100, Pt1000)
  • 4-20mA signals (from external transmitters)
• Channels: Typically 8–16 analog inputs (configurable)
• Accuracy: ±0.1% FS (Full Scale)
• Isolation: Channel-to-channel and system isolation for noise immunity.

2. Outputs & Control

• Analog Outputs: 4-20mA or 0-10V (for control signals)
• Digital Outputs: Relay contacts (24V DC, 2A) for alarms/shutdowns
• Control Logic: Supports PID-based temperature regulation.

3. Communication & Interfaces

• Backplane Connection: Integrates with Mark VI/Mark VIe via VME bus or PDBus
• Protocols Supported:
  • Modbus TCP/RTU
  • IEC 61850 (for grid communication)
  • PROFINET (optional)

4. Power & Environmental Ratings

• Power Supply: 24V DC (±10%)
• Operating Temperature: -20°C to +60°C
• Humidity: 5% to 95% (non-condensing)
• Certifications: UL, CE, IEC 61000-6-2/4 (EMC/industrial standards)

Software & Firmware

• Configuration Tool: ToolboxST (GE’s engineering software)
• Features:
  • Real-time temperature trending
  • Fault detection (sensor break, drift, etc.)
  • Redundant sensor support (for critical applications)

Key Features

1. High-Accuracy Temperature Monitoring – Ensures safe turbine operation.
2.  Flexible Input Support – Works with thermocouples, RTDs, and 4-20mA signals.
3.  Hot-Swappable – Can be replaced without system shutdown.
4. LED Diagnostics – Visual status indicators for power, comms, and faults.

Applications

• Gas Turbine Exhaust Temp Control
• Steam Turbine Overheat Protection
• Combustion Monitoring
• Power Plant Safety Systems

Documentation & Manuals

For installation and programming, refer to:

• GEH-6421 (Mark VI System Guide)
• GEH-6853 (Mark VIe System Guide)
• GEI-100746 (I/O Module Manual)
