GE SR469-P5-H-A20-T
GE SR469-P5-H-A20-T is a multifunction motor protection relay manufactured by GE (now part of Emerson) and belongs to the GE Multilin SR469 series. The suffix “P5-H-A20-T” specifies its particular configuration and functions.
According to Source 1, the GE SR469-P5-H-A20-T is a microprocessor-based multifunction motor management relay that integrates comprehensive motor protection, advanced monitoring capabilities, diagnostic tools, and control functions. Its primary goals are to maximize motor uptime, prevent equipment damage, optimize maintenance scheduling, and enhance system reliability.
Meaning of the model suffixes:
- P5: Indicates a motor rated current range of 0.5A to 5.0A AC RMS @ 1A or 5A secondary (matching CT secondary current).
- H: Indicates a wide-range AC/DC power supply, typically 24–240V AC/DC.
- A20: Refers to the communication module; “A” denotes the communication module type, and “20” indicates support for the Modbus RTU protocol.
- T: Specifies the input/output configuration, usually including 3–6 programmable digital inputs, 4–6 programmable relay outputs, and an optional analog output (4–20mA).
This model supports a variety of protection functions, including overload thermal capacity protection, stall protection, short-circuit protection, phase unbalance protection, ground fault protection, undervoltage/overvoltage protection, underpower/reverse power protection, multiple start/starting interval protection, temperature protection, load loss protection, tE time protection, and more.
The product complies with international standards such as IEC 60255, UL 508, CSA C22.2 No. 14, and CE Mark. It operates within a temperature range of -40°C to +70°C, has a storage temperature range of -40°C to +85°C, and supports 5%–95% RH humidity (non-condensing).
The GE SR469-P5-H-A20-T is a high-performance motor protection relay suitable for industrial automation, power systems, mining, metallurgy, and other sectors, and is widely used for motor protection, control, and monitoring.
