HIMA F2DO801

The HIMA F2DO801 is a high-reliability Safety Digital Output Module designed for critical safety applications requiring SIL 3 certification according to IEC 61508. It is part of HIMA’s HIMax series and is used in safety instrumented systems (SIS) such as emergency shutdown (ESD), fire and gas (F&G) systems, and process shutdown systems .

Below are the detailed technical specifications:

⚙️ 1. Basic Specifications

• Model: F2DO801
• Manufacturer: HIMA
• Type: Safety Digital Output Module
• Safety Integrity Level (SIL): SIL 3 (IEC 61508)
• Number of Channels: 8 independent output channels
• Output Type: Transistor (solid-state relay)
• Rated Voltage: 24 V DC
• Max Load Current per Channel: 0.5 A
• Leakage Current: < 0.1 mA
• Response Time: < 1 ms

🔌 2. Electrical and Isolation Characteristics

• Isolation Voltage:
  • Between channels: 500 V
  • Between channels and backplane: 1500 V
• Protection Features: Overload protection, short-circuit detection, open-circuit detection

🌡️ 3. Environmental Specifications

• Operating Temperature: -40°C to +70°C
• Storage Temperature: -40°C to +85°C
• Protection Rating: IP20

🔍 4. Diagnostics and Indicators

• Diagnostic Functions: Real-time monitoring for short-circuit, open-circuit, and load faults
• LED Indicators: Green LED per channel for status indication

📏 5. Physical Specifications

• Weight: 1 kg
• Dimensions: Compact modular design (exact dimensions not explicitly stated, but typically conforms to HIMA standard module sizes)
• Mounting: Designed for installation in HIMA standard racks

📜 6. Certifications and Compliance

• Certifications: TÜV, ATEX, IECEx, cULus
• Design Standards: IEC 61508 (SIL 3)

🏭 7. Applications

• Used in high-integrity safety systems such as:
  • Emergency shutdown (ESD) systems
  • Fire and gas (F&G) detection systems
  • Process shutdown systems
  • Critical control applications in oil and gas, chemical, and power industries

💎 Conclusion

The HIMA F2DO801 is a robust and highly reliable safety output module designed for critical applications where failure is not an option. Its fast response time, comprehensive diagnostics, and SIL 3 certification make it suitable for industries requiring the highest levels of safety and reliability 1.

HIMA Company Introduction

HIMA is a leading global manufacturer of safety control systems, headquartered in Landau, Germany.

The company was founded in 1908 and has a history of over 110 years. HIMA is committed to providing safe and reliable solutions for industrial automation applications, and its products are widely used in industries such as oil and gas, chemical, power, steel, and automotive.
