🔧 Detailed Technical Specifications of the HIMA Z7136 Controller Module

The HIMA Z7136 is a safety controller module specifically designed for industrial automation control systems, particularly for high-risk environments such as chemical, oil, and natural gas industries. Developed by HIMA, a leading German manufacturer in the global safety control systems sector, this module offers high reliability and flexibility, meeting stringent safety standards (e.g., SIL3 certification). Below are the detailed technical specifications compiled based on search results:

📌 1. Basic Parameters

• Brand & Model: HIMA Z7136.
• Structure: Modular design, supporting compact installation.
• Installation Method: DIN rail mounting, fanless cooling, IP20 protection rating (suitable for control cabinet environments).
• Weight & Dimensions:
  • Weight: Approximately 0.5 kg (some sources indicate 1 kg, possibly due to different configurations).
  • Dimensions: 120 mm × 70 mm × 110 mm (some sources list 1 mm × 1 mm, likely an error or simplification).
• Operating Environment:
  • Operating Temperature: -20°C to +60°C (storage temperature: -40°C to 85°C).
  • Humidity: Not explicitly specified, but typically suitable for industrial humidity ranges (e.g., 5%-95% non-condensing).

⚡ 2. Electrical Characteristics

• Power Requirements: 24V DC power supply.
• Input/Output (I/O) Points:
  • Digital Input/Output: 16 digital channels.
  • Analog Input/Output: 2 analog channels.
  • Total I/O Points: 50 points (may include communication interfaces).
• Processing Performance:
  • Processing Speed: 150/60 Hz (likely referring to cycle processing frequency).
  • Program Capacity: 50,000 steps.
  • Data Capacity: 100 registers or data blocks.
• Communication Interfaces:
  • Supports protocols such as Modbus RTU, RS-232/RS-485, Ethernet, facilitating integration into existing industrial networks.

🛡️ 3. Safety & Certifications

• Safety Level: Complies with IEC 61508 standards, supports SIL3 (Safety Integrity Level 3) certification, suitable for high-safety applications.
• Protection Features:
  • Fanless design reduces failure points and enhances reliability.
  • Wide operating temperature range for harsh environments.
• Application Fields:
  • Primarily used in safety control systems for hazardous environments, such as petrochemicals, power, pharmaceuticals, steel, cement, and energy industries.

📊 4. Functional Features

• High Performance & Reliability: Utilizes advanced materials and design to ensure high stability and long service life.
• Flexible Configuration: Supports various I/O expansions and communication protocols, adaptable to complex control systems.
• Diagnostics & Maintenance: Built-in status monitoring, supports regular inspections to minimize unexpected downtime.

💎 Summary

The HIMA Z7136 is a high-performance, highly reliable safety controller module suitable for demanding industrial environments. Its core advantages include SIL3 certification, compact design, flexible communication options, and broad industry applicability.
