Technical Parameter

GE IC695ALG508-AA Industrial Automation Module

The GE IC695ALG508-AA is an industrial automation module manufactured by General Electric (GE), designed for use within the PACSystems RX3i series. This module is primarily used for collecting signals from Resistance Temperature Detectors (RTDs). Below are the detailed features and functions of this module:

Channel Configuration:

1. 8 independent differential RTD input channels, each supporting isolation to enhance resistance to interference and ensure measurement accuracy.

2. Supports various RTD types, including PT100, PT1000, Ni618, Ni672, NiFe518, and Cu426, covering a resistance range from 25 ohms to 426 ohms.

Technical Specifications:

1. Each channel supports 32-bit integer or 16-bit IEEE floating-point data input format, with a resolution of 16 bits.

2. Temperature units can be configured as Celsius, Fahrenheit, or Ohms, providing flexibility for different industrial environments.

3. Operating temperature range: -200°C to +85°C, making it suitable for harsh industrial environments.

Installation and Compatibility:

1. Must be installed on the RX3i Universal Backplane, requiring RX3i CPU firmware version 5.5 or higher.

2. Supports a variety of terminal block types, including box-type, extension box-type, spring-type, and extended spring-type, offering flexibility for different installation needs.

Functional Features:

1. User Scaling: Allows for linearization of input signals to improve measurement accuracy.

2. Programmable Filter Settings: Frequency range from 36 Hz to 694 Hz to reduce noise interference.

3. Fault Detection & Alarming: Monitors the module’s status in real-time and alerts users to any anomalies.

4. Thermocouple Compensation: Ensures accurate temperature measurements, especially in precision-required applications.

Applications:

1. Widely used in industrial automation fields such as process control, energy management, and building automation.

2. Particularly well-suited for applications requiring high-precision temperature measurements, including petrochemical, metallurgy, and power industries.

Other Information:

1. The module uses high-speed patented technology and supports hot-swapping, allowing for safe insertion or removal while powered on.

2. Comes with one year warranty and global technical support.

Conclusion:

The GE IC695ALG508-AA is a high-performance, reliable industrial automation module, ideal for precise temperature measurement in complex industrial environments. Its flexible configuration options and robust features make it an essential component for industrial control systems.
