Operating Voltage:24V DC
Relay Type:SPDT
Contact Rating:10A @ 240V AC, 16A @ 30V DC
Number of Relays:1
Operating Temperature:-10°C to +55°C
Humidity Range:5% to 95% RH (non-condensing)
Size (WxHxD):35mm x 20mm x 20mm
Connection Type:Terminal Block
Insulation Resistance:≥100MΩ
Leakage Current:≤10μA
Switching Speed:≤1ms
Mechanical Life:≥10,000,000 cycles
Electrical Life:≥10,000,000 cycles
The Mitsubishi CM150DY-24A Precision Control Module is designed with exceptional compactness and a uniform design, making it perfect for space-constrained industrial settings.
Its quick commissioning feature, enabled by application macros and panel assistants, reduces setup time significantly, enhancing operational efficiency.
The standard safe torque off function (SIL3) ensures enhanced safety during operation.
Featuring sensorless vector control for induction and permanent magnet motors up to 599 Hz, this module provides precise and efficient control.
Integrated braking chopper and coated circuit boards offer additional reliability and durability, especially in harsh environments.
Additionally, the IP66 product variant is specially designed to withstand challenging conditions, including dust and water exposure, while the solar pump drive variant offers versatility in renewable energy applications.
There are no reviews yet.
