MOOG G772K240A Servo Valve Overview

MOOG G772K240A is a high-performance two-stage electro-hydraulic servo valve from the G770 series, designed for precise control of hydraulic flow, pressure, position, speed, and force in demanding industrial and aerospace systems.

1) Product Summary

The G772K240A converts an analog electrical signal into a proportional hydraulic flow output, enabling extremely accurate closed-loop motion control. It is widely used in aerospace testing, power plants, metallurgy, heavy machinery, and industrial automation.

Typical roles

Flight simulators & aerospace test rigs
Steel rolling mill hydraulics
Injection molding machines
Turbine & power plant control
Automotive durability testing

2) Key Features

Servo valve architecture

2-stage design with torque-motor driven pilot stage
Dual-nozzle flapper pilot and spool-type power stage
Mechanical feedback via cantilever spring
Fail-safe spring-centered spool (returns to neutral on signal loss)

Performance highlights

High dynamic response and bandwidth
High resolution & low hysteresis
Excellent linearity and repeatability
Rugged stainless-steel construction
Field adjustable null bias

3) Technical Specifications (Typical)

Parameter	Value
Type	Two-stage electro-hydraulic servo valve
Rated pressure	up to 210 bar / 3000 psi
Flow capacity	up to 240 L/min (variant dependent)
Command signal	±10 V or 4–20 mA
Rated current	~37 mA
Frequency response	≥60–150 Hz (config dependent)
Hysteresis	<0.1–1% FS
Temperature range	−54°C to +120°C (approx.)
Medium	Hydraulic oil
Mounting	Baseplate

4) Advantages in Real Applications

Precision control

Accurate position, force and speed control for closed-loop systems
Very fast response enables dynamic testing and motion simulation

Reliability & safety

Fail-safe neutral position if signal lost
Long service life and contamination-resistant design

Flexibility

Can operate as 3-way or 4-way flow control valve
Compatible with many hydraulic fluids and harsh environments

5) Maintenance & Installation Notes

Hydraulic oil must be filtered to ≤10 μm cleanliness.
System flushing required before installation.
Sealed oil tank with air filtration recommended.

6) Lifecycle / Replacement Info

Some distributors list G772K240A as discontinued or replaced by newer variants within the G77X family.
