Operating Temperature Range:-20°C to +70°C
Operating Voltage:24VDC
Current Consumption:Less than 1A
Communication Interface:RS-485 Modbus TCP
Maximum Output Current:1A per channel
Number of Channels:2
Motion Profile:Sinusoidal, Trapezoidal, Linear
Position Accuracy:±0.01mm
Velocity Accuracy:±0.1%
Resolution:0.1μm
The NM Nanomotion AB1A-2a-HR-E4 precision motion control module is engineered to deliver unparalleled performance in demanding industrial environments. Its high-resolution capabilities ensure precise positioning, critical for applications requiring accuracy down to the sub-micron level.
Equipped with an advanced Ethernet communication interface, this module seamlessly integrates into modern industrial networks, facilitating real-time data exchange and control. It supports a wide range of AC/DC motors, making it versatile for various automation needs.
With a robust design capable of operating within extreme temperature conditions from -20°C to +70°C, this motion control module ensures reliability in harsh environments. It features an IP67 enclosure rating, protecting against dust and water ingress, ensuring continuous operation even under adverse conditions.
The NM Nanomotion AB1A-2a-HR-E4 is designed with user convenience in mind. It comes with comprehensive documentation and support resources, simplifying installation and maintenance processes. The intuitive user interface allows for easy configuration and monitoring of motion parameters.
For applications requiring high-speed precision, this module is the preferred choice. Its ability to operate at speeds ranging from 0.1 to 5000 RPM, coupled with its exceptional load capacity of up to 2 kg, makes it suitable for a wide array of tasks, from delicate assembly operations to heavy-duty material handling.
