Schneider AS-B805-016 is a discrete input module used in Schneider Electric’s Modicon PLC (Programmable Logic Controller) systems. It is a core component specifically designed to transmit on/off field signals—such as push buttons, limit switches, and sensor contact states—to the PLC controller.
Below are the key technical specifications and application notes for this module:
1. Basic Specifications
- Model: AS-B805-016
- Type: Discrete Input Module
- Supply Voltage: 115 VAC
- Number of Input Points: 16 points (16P)
- Rated Input Current: Approx. 6 mA (typical)
- Form Factor: Occupies one slot in an 800-series rack
- Compatible Platforms: Modicon AEG, Modicon Quantum, Modicon TSX (including Premium / Compact series)
2. Key Performance Parameters
- Response Time:
- OFF to ON: 6 ms
- ON to OFF: 18 ms
- Operating Frequency Range: 47 Hz – 63 Hz (standard AC supply range)
- Operating Temperature Range: –5 °C to +55 °C (industrial grade)
3. Operating Principle and Applications
- Signal Acquisition:
The module converts field voltage signals into PLC-readable digital signals (0/1) using internal resistor dividers or opto-isolation technology. - Typical Applications:
Widely used in packaging machinery, textile equipment, material handling systems, and automated assembly lines for monitoring motor status, detecting limit switches, and reading sensor signals.
4. Compatibility and Conversion
- Cross-Platform Compatibility:
This module is primarily designed for the Modicon B-series (such as B805, B853, etc.). When used in Modicon TSX systems, a field wiring adapter module (e.g., AS-B210) is typically required to convert the physical rack interface. - Wiring Method:
Commonly connected to the system I/O area via a 20-pin flat connector.
Summary
If you are looking for a stable and well-proven discrete input module for receiving 115 VAC switching signals, the AS-B805-016 is a classic and widely adopted solution.
