SCHNEIDER AS-B872-100 is an analog output module from the Modicon 800 series manufactured by Schneider Electric.
Below are the key specifications and features of this product:
1. Core Specifications
- Model: AS-B872-100
- Type: Analog Output Module
- Output Characteristics:
- Signal Type: 4–20 mA current loop
- Number of Channels: 4 channels
- Application: Commonly used to control devices that require precise analog control, such as control valves and variable frequency drives (VFDs).
2. Compatible Platform
- This module is typically used in conjunction with the Modicon M340 series PLC and is installed in the controller’s I/O expansion slot.
- It is part of the Modicon 800 series I/O modules.
3. Physical Characteristics (Reference to Similar Models)
- Although complete dimensional data for this specific model is not directly available, based on the physical dimensions of the similar AS-B872-200 analog output module from the same series, the AS-B872-100 is expected to have comparable dimensions:
- Dimensions: Approximately 88 mm × 36 mm × 23 mm (L × W × H)
- Weight: Approximately 100 g
- Connection Method: 32-pin spring connector (compliant with DIN 3204 standard).
4. Typical Applications
This module is widely used in automation control systems and is primarily responsible for outputting analog control signals, including:
- Valve Control: Such as electric actuated valves (EAVs) and proportional valves.
- Drive Control: Such as speed control of variable frequency drives (VFDs).
- Instrument Supply: Providing current signals to instruments such as ammeters and flowmeters.
Summary
The AS-B872-100 is a dedicated analog output module designed for 4–20 mA current signal output. With four output channels, it is commonly used in precision process control applications.
