SCHNEIDER B824 is a discrete output module manufactured by Schneider Electric, commonly used in Modicon series PLC (Programmable Logic Controller) systems. Below is a detailed description of this product:
1. Product Specifications
- Voltage Rating: 24 V DC
- Number of Outputs: 16 points (16-Point)
- Output Type: True High
- Power Supply Requirement: 12 / 24 V DC
- Typical Applications: Suitable for controlling low-power loads such as relays and contactor coils
2. Electrical Characteristics
- Switching Current: 1.2 A (at 10 V)
- Holding Current: 0.5 A (at 24 V)
- Insulation Resistance: > 10 MΩ
- Dielectric Strength: 500 V AC / 700 V DC
3. Physical Characteristics
- Dimensions: 1U height (approximately 44.45 mm), designed for installation in a standard 19-inch rack
- Operating Temperature Range: 0 °C to +50 °C
- Protection Rating: IP20 (basic protection, suitable for non-field installation environments)
4. Notes and Precautions
- Power Configuration: Ensure the module power supply is compatible with the PLC system, typically requiring a 12 V or 24 V DC supply.
- Load Connection: When connecting loads (such as relays), make sure the load current does not exceed the module’s rated current.
- Fault Diagnosis: The module is typically equipped with indicator LEDs for real-time monitoring of output status.
Summary
The SCHNEIDER B824 is a reliable 24 V DC, 16-point discrete output module widely used in industrial automation control systems.
