1. Key Electrical Parameters
- Rated Current: 6 A
(The rated current refers to the maximum current that can flow through the relay during normal operation.) - Number of Poles: 1P (single pole), meaning the relay has only one circuit contact (typically a single switching function).
- Tripping Characteristic: C
(C-type tripping characteristic indicates that the relay will trip when the current exceeds 5–10 times the rated current.) - Power Consumption:
- Standby power: approx. 5.4 W
- Operating power: approx. 5.4 W
- Contact Characteristics:
- Minimum operating voltage: 17 V
- Minimum operating current: 5 mA
- Non-overlap time: approx. 1.5 ms
(The time difference between the opening and closing of the contacts.) - Mechanical life: approx. 30 million operations
2. Mechanical and Environmental Parameters
- Mechanical Endurance: 30 million operations
(This represents the maximum number of switching operations without electrical load.) - Insulation Resistance: > 10 MΩ
- Protection Rating: IP20
(Provides protection against accidental contact only; not waterproof.) - Mounting Dimensions:
- Height: 77 mm
- Width: 45 mm
- Depth: 93 mm
- Weight: approx. 0.58 kg
3. Typical Applications
Due to its 1-pole design and C-type tripping characteristic, this relay is commonly used for:
- Circuit Protection:
Protecting circuits in the event of short circuits or overload conditions (when current exceeds 5–10 times the rated current). - Control Circuits:
Controlling the on/off switching of main circuits in motor control systems, variable frequency drives (VFDs), or industrial automation systems.
Note:
This model is a general-purpose overload relay under the Schneider Electric brand. It is mainly used to protect motors and their control circuits, preventing damage to electrical equipment caused by overcurrent.
