Schneider TM258LD42DT

Schneider TM258LD42DT is a compact logic controller from Schneider Electric’s Modicon M258 series, featuring the following key characteristics:

I/O Configuration

The base unit provides 42 discrete I/O points.
Built-in 4 analog inputs (or 4 extended I/O channels).
Equipped with 1 Ethernet port.

Power Supply

24 V DC power input.
Input signal interpretation: ≥15 V = “1”, ≤5 V = “0”.
Input current: 4 mA.
Input impedance: 6 kΩ.

Communication

Supports CANopen and Ethernet (TCP/IP) communication.
Can be expanded using the Modicon TM5 modular I/O system for larger applications.

Environmental & Compliance

Complies with RoHS, REACH, and other EU environmental directives.
Contains no toxic heavy metals, no mercury, and no PVC, with corresponding declarations of conformity available.

Applications

Designed for general machinery control such as packaging, conveying, and crane systems.
Suitable for industrial automation scenarios requiring compact size and highly integrated I/O.

Dimensions

Approx. 175 mm × 99 mm × 85 mm (L × H × W), making it easy to install in space-constrained control cabinets.

Summary

The TM258LD42DT operates on 24 V DC, offers 42 discrete I/O points and several analog inputs, supports Ethernet and CANopen communication, complies with the latest environmental standards, and is ideal for small to medium-sized machinery automation projects.
