Schneider TSXCDP203 Connection Cable Overview

Item	Description
Product Name	TSXCDP203 Connection Cable
Compatible Series	Schneider Modicon Quantum, Modicon Premium, Telemecanique PLC series, etc.
Cable Type	Round flying lead (HE 10 connector)
Length	2 meters
Conductor Specification	22 AWG (0.324 mm²)
Terminals	HE 10 connectors on both ends (compatible with Modicon PLC module ports)
Operating Temperature Range	-25 °C to +70 °C (compliant with IEC 60228)
Voltage Rating	600 V (rated voltage)
Materials	Low-smoke, halogen-free (LSZH) PVC jacket, RoHS compliant
Environmental Statement	Not included in the global recycling program, but Schneider promotes circular use of materials through its “Use Better, Use Longer, Reuse” initiative, aiming for net-zero emissions by 2050
Common Applications	– Signal/power interconnection between PLC modules

Fieldbus wiring (CANopen, Modbus)
Field I/O expansion |
| Packaging / Ordering | Standard packaging: single 2-m cable. Product number TSXCDP203. Available through Schneider authorized distributors or online platforms |

Key Features

High Reliability:
The HE 10 connectors use a metal spring-locking mechanism to prevent loosening, ideal for vibration-prone industrial environments.

Flexible Installation:
The 2-meter length suits most cabinet-internal wiring or cabinet-to-field I/O connections, providing a balance between compact routing and preventing signal attenuation caused by excessively long cables.

Strong Compatibility:
Designed specifically for Schneider PLCs (Modicon Quantum and Premium). Simply plug in to complete power/signal connection—no additional terminal blocks required.

Environmentally Friendly Materials:
The LSZH jacket reduces harmful gas emissions during fire events and complies with EU RoHS requirements.

Selection Guide

Different lengths required:
Choose TSXCDP053 (0.5 m) or TSXCDP503 (5 m), which share identical specifications except for length.
Flat cable option:
Consider the TSXCDP102 / 202 / 302 series, which use the same HE 10 connectors but feature a flat-cable structure suitable for space-constrained wiring environments.
Higher-current applications:
For higher-current needs, use TSXCDP501 (bare-wire type) or other cables with larger conductor sizes.

Summary

The TSXCDP203 is a 2-meter round connection cable equipped with HE 10 connectors on both ends and built with 22 AWG conductors. Designed for inter-module connections in Schneider PLC systems, it offers reliable mechanical locking, solid electrical performance, and environmentally compliant materials. It is one of the commonly used standard interconnection cables in industrial automation environments.
