TRICONEX 3002 digital output (DO) module

TRICONEX 3002

The Triconex 3002 is a digital output (DO) module from the Tricon v9 safety system, designed for high-reliability, fault-tolerant control in critical applications such as Emergency Shutdown Systems (ESD), Fire & Gas Systems, and Process Safety.

TRICONEX 3002 Technical Specifications

1. General Specifications

• Module Type: Digital Output (DO)
• Safety Certification: SIL 3 (IEC 61508)
• Redundancy Support: TMR (Triple Modular Redundancy)
• Compatibility: Tricon v9 (and some legacy systems)

2. Output Channels

• Number of Channels: 8 channels (isolated, high-current)
• Output Type:
  • Form C Relay (SPDT – Single Pole Double Throw)
  • Contact Rating:
    • 5A @ 30V DC (resistive)
    • 5A @ 250V AC (resistive)
    • 2A @ 30V DC (inductive)
    • 2A @ 250V AC (inductive)

3. Electrical Characteristics

• Switching Time:
  • Turn-On: ≤ 10ms
  • Turn-Off: ≤ 10ms
• Isolation:
  • Channel-to-Channel: 1500V AC
  • Channel-to-System: 2500V AC
• Max Switching Frequency: 10Hz (inductive loads)

4. Diagnostics & Safety Features

• Contact Feedback Monitoring (verifies relay state)
• Short-Circuit Protection
• Overload Protection
• Fault Reporting to Main Processor

5. Power Requirements

• Supply Voltage: 24V DC (from Tricon backplane)
• Power Consumption: ~ 5W (depends on load)

6. Environmental & Mechanical

• Operating Temperature: -40°C to +70°C
• Humidity: 5% to 95% (non-condensing)
• Mounting: Fits in Tricon v9 chassis
• Certifications: ATEX, IECEx, UL, CE (as applicable)

Applications

• Emergency Shutdown (ESD) Systems
• Motor & Valve Control
• Critical Process Interlocks
• Fire & Gas Safety Systems

Main Brand:

ABB      Allen-Bradley      Alstom      Bently         Emerson     Foxboro

GE       MOOG       Schneider       Woodward       HIMA        Honeywell

First hand source, affordable price. Spot inventory!

•Shipping Port: Xiamen

•Ship to you via Fedex/DHL/TNT/UPS/EMS

•Package: Original packing with cartons

First hand source // Quality assurance // Fast delivery time // Feel free to purchase with confidence

GE DS200TCTGG1A FF    GE DS200QTBAG1A     GE DS200RTBAG2A HC

GE DS200TBQCG1 ABB    GE DS200TCRAG1A     GE DS200TBCAG1A

GE DS200PCCAG4 ADB    GE DS200TBQAG1A     GE DS200EXPSG1ACB

GE 531X307LTBAKGI     GE DS200CTBAG1 ADD  GE DS200QTBAG1A DC

What is a DCS?

A Distributed Control System (DCS) is a sophisticated, computer-based control system designed to automate, monitor, and manage complex industrial processes. It is widely used in large-scale industrial facilities such as refineries, power plants, chemical plants, and paper mills, where precision, reliability, and scalability are critical.

How Does a DCS Work?

A DCS is composed of several interconnected components that work seamlessly to ensure efficient process control. Here’s a breakdown of its key elements:

1. Controllers:
   These are the “brains” of the system. Controllers receive data from sensors, process it using pre-programmed logic, and send output signals to actuators to maintain optimal process conditions.
2. Sensors:
   Sensors act as the “eyes and ears” of the system, measuring critical physical parameters such as temperature, pressure, flow rate, and level. This real-time data is essential for accurate control.
3. Actuators:
   Actuators are the “muscles” of the system. They execute physical actions based on controller commands, such as opening/closing valves, starting/stopping motors, or adjusting dampers.
4. Operator Stations:
   These serve as the human-machine interface (HMI), allowing operators to monitor the process, adjust setpoints, and troubleshoot issues. Modern DCS systems often feature intuitive graphical interfaces for ease of use.
5. Communication Network:
   The backbone of the DCS, this network connects all components, enabling seamless data exchange and coordination. It ensures that every part of the system works in harmony, even across large industrial sites.

Why is a DCS Important?

• Centralized Control with Distributed Execution: A DCS allows for centralized monitoring while distributing control functions across multiple controllers, reducing the risk of system-wide failures.
• Scalability: It can easily expand to accommodate growing operational needs.
• Reliability: Redundant systems and fail-safes ensure continuous operation, even in critical environments.
• Efficiency: Optimizes processes, reduces waste, and improves overall productivity.

==========================================================================================
