TRICONEX 3005 digital output (DO) module

TRICONEX 3005

The Triconex 3005 is a digital output (DO) module designed for high-reliability, fault-tolerant control in critical safety systems. It is part of the Tricon v9 series and is widely used in Emergency Shutdown Systems (ESD), Fire & Gas Systems, and other SIL 3-rated applications.

TRICONEX 3005 Technical Specifications

1. General Specifications

• Module Type: Digital Output (DO)
• Safety Certification: SIL 3 (IEC 61508)
• Redundancy Support: TMR (Triple Modular Redundancy)
• Compatibility: Tricon v9 (and some legacy systems)

2. Output Channels

• Number of Channels: 8 channels (isolated, high-current)
• Output Type:
  • Form C Relay (SPDT – Single Pole Double Throw)
  • Contact Rating:
    • 5A @ 30V DC (resistive)
    • 5A @ 250V AC (resistive)
    • 2A @ 30V DC (inductive)
    • 2A @ 250V AC (inductive)

3. Electrical Characteristics

• Switching Time:
  • Turn-On: ≤ 10ms
  • Turn-Off: ≤ 10ms
• Isolation:
  • Channel-to-Channel: 1500V AC
  • Channel-to-System: 2500V AC
• Max Switching Frequency: 10Hz (inductive loads)

4. Diagnostics & Safety Features

• Contact Feedback Monitoring (verifies relay state)
• Short-Circuit Protection
• Overload Protection
• Fault Reporting to Main Processor

5. Power Requirements

• Supply Voltage: 24V DC (from Tricon backplane)
• Power Consumption: ~ 5W (depends on load)

6. Environmental & Mechanical

• Operating Temperature: -40°C to +70°C
• Humidity: 5% to 95% (non-condensing)
• Mounting: Fits in Tricon v9 chassis
• Certifications: ATEX, IECEx, UL, CE (as applicable)

Key Differences Between Triconex 3002 and 3005

• 3005 has a higher contact rating (5A vs. 2A for 3002 in some conditions)
• 3005 is optimized for mixed AC/DC loads
• 3005 includes enhanced diagnostics for relay health monitoring

Applications

• Emergency Shutdown (ESD) Systems
• Motor & Valve Control
• Critical Process Interlocks
• Fire & Gas Safety Systems
