TRICONEX 3564
The Triconex 3564 is part of the Tricon safety instrumented system (SIS) by Schneider Electric, designed for high-integrity process control and emergency shutdown applications. Below are the key technical parameters for the Triconex 3564 module:
Triconex 3564 (Analog Output Module) – Key Specifications:
1. Type: Analog Output (AO) module
2. Channels: Typically 4 or 8 channels (varies by model)
3. Output Signal:
-
- Current: 4-20 mA (standard)
- Voltage: 0-10 V DC or other configurable ranges (depends on configuration)
4. Resolution:
-
- 16-bit (high precision) for accurate analog output
5. Load Capacity:
-
- Supports up to 500 Ω load (for current output)
6. Isolation:
-
- Channel-to-channel isolation for safety and noise reduction
7. Communication:
-
- Interfaces with the Tricon Main Processor via the TriBus
8. Diagnostics:
-
- Self-testing & fault detection (supports online diagnostics)
- Fail-safe operation (supports redundant configurations)
9. Redundancy Support:
-
- Can be used in TMR (Triple Modular Redundant) configurations
10. Power Supply:
-
- Typically 24V DC (varies based on system configuration)
11. Certifications:
-
- Compliant with IEC 61508 (SIL 3) and ISA S84 for safety applications
12. Operating Temperature:
-
- -40°C to +70°C (industrial-grade)
13. Mounting:
-
- Designed for Triconex chassis (supports hot-swapping in some configurations)
Applications:
- Process control systems (oil & gas, chemical, power plants)
- Emergency shutdown (ESD) systems
- Fire & gas safety systems
Compatibility:
- Works with Tricon v9/v10/v11 systems
- Integrates with Triconex engineering tools (Trilog, TriStation)
