The Triconex 3601E is part of the Tricon v9–11 series by Schneider Electric, designed for high-integrity safety and critical control applications. Below are its key technical parameters:

General Specifications:

• Manufacturer: Triconex (Schneider Electric)
• Model: 3601E
• Series: Tricon v9, v10, or v11 (depending on firmware)
• Type: Digital Input Module
• Function: Safety-certified input module for process control systems

Electrical Specifications:

• Input Channels: Typically 16 or 32 channels (depends on configuration)
• Input Type: 24V DC (sinking/sourcing)
• Voltage Range:
  • Nominal Input Voltage: 24V DC
  • Operating Range: 10–30V DC
• Input Current: ~5–10 mA per channel (typical)
• Isolation: Channel-to-channel and channel-to-system isolation
• Response Time: <10 ms (configurable)

Environmental & Mechanical:

• Operating Temperature: -40°C to +70°C
• Storage Temperature: -40°C to +85°C
• Humidity: 5–95% (non-condensing)
• Mounting: DIN rail or panel-mounted
• Enclosure Rating: Typically IP20 (for control cabinet use)

Certifications & Compliance:

• Safety Standards:
  • IEC 61508 (SIL 3)
  • TÜV, Exida certified
• EMC Compliance: EN 61326, EN 61000-6-2/4
• Hazardous Area Certifications: Optional (if applicable)

Communication & Diagnostics:

• Communication Protocol: Proprietary Triconex communication (TriBus)
• Diagnostics:
  • Channel fault detection
  • Open/short-circuit detection
  • LED status indicators per channel

Compatibility:

• Works with Tricon v9, v10, v11 systems
• Integrates with Triconex Safety Instrumented Systems (SIS)

Typical Applications:

• Emergency Shutdown Systems (ESD)
• Fire & Gas Systems (FGS)
• Turbomachinery Control
• Critical process shutdowns
