TRICONEX 3805H
The Triconex 3805H is a High-Density Digital Input Module from the Tricon v9–v11 safety system by Schneider Electric (formerly Invensys/Triconex). Below are its key technical parameters:
Triconex 3805H Digital Input Module Specifications
1. Type:
- High-density digital input (DI) module (safety-rated for critical applications).
2. Input Channels:
- 32 channels (supports a large number of inputs in a single slot).
3. Input Signal Compatibility:
- Voltage Range: Typically 24V DC (standard for industrial control systems).
- Dry Contact/Wet Contact Support: Compatible with both (sink/source configurations).
- Field Wiring: Removable terminal blocks for easy installation.
4. Isolation & Safety:
- Channel-to-Channel Isolation: Prevents cross-talk and interference.
- Fault Detection: Built-in diagnostics for open wires, shorts, and field device failures.
- SIL Rating: Designed for SIL 3 (Safety Integrity Level 3) applications (IEC 61508/61511).
5. Response Time:
- Typically <10 ms (configurable via TriStation software).
6. Communication:
- Interfaces with the Tricon Main Processor via the TriBus (Triconex backplane).
- Supports Tricon v9, v10, and v11 systems.
7. Power Consumption:
- Backplane-Powered (no external power required).
- Typical draw: <5W (varies based on active channels).
8. Environmental Ratings:
- Operating Temperature: -40°C to +70°C (industrial-grade).
- Humidity: 5–95% non-condensing.
- Certifications: Compliant with CE, ATEX, IECEx (for hazardous areas if applicable).
9. Redundancy & Fault Tolerance:
- Supports Triple Modular Redundancy (TMR) when used in a Tricon system.
- Hot-swappable (for maintenance without system shutdown).
10. Compatibility:
- Works with TriStation 1131 (configuration software).
- Integrates with Tricon Communication Modules (e.g., 4351B, 4009) for network connectivity.
Applications
- Safety Instrumented Systems (SIS)
- Emergency Shutdown Systems (ESD)
- Fire & Gas Systems (FGS)
- Process Control in Oil & Gas, Power, Chemical Plants
