Overview of XYCOM XVME-505/2 (70505-002)

Product Positioning:
An industrial control/I/O module based on the VME64x bus, designed for high-reliability applications such as CNC machine tools, energy systems, and manufacturing industries.

Main Functions

• Analog I/O: Provides multiple analog input/output channels (the exact number depends on the specific sub-model), supporting standard signals such as 0–10 V and 4–20 mA.
• Digital I/O: Optional digital input/output expansion, compatible with a wide range of sensors and actuators.
• Multi-protocol Communication: Supports industrial Ethernet protocols such as EtherCAT, Profinet, and EtherNet/IP, enabling easy integration with higher-level systems.

Hardware Specifications

• Bus Standard: VME64x (compatible with VMEbus)
• Processor: Built-in high-performance CPU (specific model not disclosed), with clock speeds in the several-hundred-MHz range to meet real-time control requirements.
• Memory: Combination of RAM and Flash, with capacities of several tens of megabytes or more, supporting local program and parameter storage.
• Expansion Slots: Multiple VME expansion slots, allowing cascading with other XYCOM modules (such as the XVME-688 and XVME-540).

Software and Programming

• Supports IEC 61131-3 standard programming languages (Ladder Diagram, Function Block, Structured Text, etc.), and provides user-defined function blocks and graphical symbol libraries.
• A unified global database shared by all devices within the system ensures data consistency and reduces configuration costs.

Reliability

• Industrial-grade protective design, capable of stable operation over a wide temperature range and in environments with strong vibration and electromagnetic interference.
• Free replacement within the warranty period; after-sales support includes system upgrades and technical consulting.

Typical Applications

• High-precision CNC machine tools
• Power system monitoring and protection
• Automated production lines and process control
• Field control nodes in transportation, medical, and related industries

Summary

The XYCOM XVME-505/2 is a highly reliable VME64x module that integrates analog and digital I/O, multi-protocol industrial Ethernet, and IEC 61131-3 programming support. It is well suited for complex industrial automation systems that require a unified database and modular expansion.
