Xycom XVME-530 70530-001
Xycom XVME-530 (Part Number 70530-001) Overview
The Xycom XVME-530 is an 8-channel analog output (AOUT) module based on the VME-bus architecture, commonly identified by part number 70530-001. It provides high-precision, isolated voltage or current outputs for industrial automation systems, making it suitable for a wide range of control and measurement applications.
1. Key Features
| Feature | Description |
|---|---|
| Channels | 8 independent D/A output channels |
| Resolution | 12 bits per channel |
| Output Mode | Jumper-selectable for voltage or current output |
| Voltage Ranges | 0–5 V, 0–10 V, ±2.5 V, ±5 V, ±10 V |
| Current Range | 4–20 mA (individual mode) |
| Optical Isolation | 300 V isolation per channel to prevent digital noise interference |
| Accuracy | Total error ≤ ±0.5 LSB; adjustable gain and offset |
| Power Supply | Onboard DC/DC converter compatible with standard VME-bus power |
| Compatibility | Fully compatible with Xycom standard I/O architecture; fits 6U VME-bus chassis |
2. Technical Specifications
- Resolution: 12 bits
- Channel Configuration: Each channel independently configurable (voltage/current)
- Voltage Output Ranges: 0–5 V, 0–10 V, ±2.5 V, ±5 V, ±10 V
- Current Output Range: 4–20 mA
- Optical Isolation: 300 V per channel
- Accuracy: ±0.5 LSB (adjustable gain and offset)
- Power Input: Standard VME-bus 5 V / 12 V with internal DC/DC conversion
- Physical Dimensions: 6U VME-bus card (approx. 233 mm × 100 mm)
3. Typical Applications
- Process Control: Driving proportional valves, variable-speed actuators, and other analog control elements
- Instrumentation and Measurement: Providing calibration voltage/current signals to test instruments
- Recording and Display Systems: Supplying analog signals to oscilloscopes or recorders for signal acquisition
- Automation Systems: Used as an analog output expansion module in PLCs, DCSs, or embedded controllers
Summary
The Xycom XVME-530 (70530-001) is a high-performance, reliable 8-channel analog output module that combines configurable voltage/current ranges, per-channel optical isolation, and low error characteristics. It is widely used in industrial automation, process control, and instrumentation calibration applications where precision and isolation are critical.
