XYCOM XVME-560
XYCOM XVME-560 is a VMEbus 32-channel analog input module introduced by Xycom (Xiongba Automation), with the common part number 70560-001.
Main Technical Specifications
| Parameter | Description |
|---|---|
| Number of Channels | 32 (Single-Ended) or 64 (Differential) Analog Inputs |
| Resolution | 12-bit (14-bit or 16-bit optional) |
| Sampling Rate | Up to 50 kHz (20 kHz optional) |
| Input Voltage Range | Selectable via jumper: ±10 V, ±5 V, ±2.5 V, 0-10 V, 0-5 V, etc. |
| Gain Settings | 1, 2, 4, 8 (Software Programmable) |
| Trigger/Interrupt | Supports VMEbus interrupts at any level (1-7) |
| DMA Transfer | Supports high-speed DMA acquisition |
| Power Supply | Standard VMEbus power (+5 V, +12 V) |
| Form Factor | VMEbus Double-Width Card (Backplane Compatible) |
| Firmware Version | e.g., F/W REV 1.2 (70560-001) |
Features
- High Density: Provides 32 analog input channels simultaneously, suitable for acquiring signals from a large number of sensors.
- Flexible Voltage/Gain Configuration: Can meet the range requirements of different sensors.
- Software Gain and Offset Adjustment: Facilitates calibration via the host computer.
- DMA and Interrupt Support: Enables high-speed data acquisition with low CPU usage.
- VMEbus Backplane Compatible: Can be directly inserted into a standard VME crate.
- Optional Resolution/Sampling Rate: Users can configure based on accuracy or bandwidth needs.
Common Application Scenarios
- Analog signal acquisition (e.g., temperature, pressure, flow) in industrial process control systems.
- High-speed data acquisition in laboratory or semiconductor equipment.
- Applications requiring multi-channel synchronous sampling in automation systems.
Brief Conclusion
The XYCOM XVME-560 is a high-channel-count, programmable gain, 12-bit (with optional higher resolution) analog input card for the VMEbus platform. It supports DMA and interrupts and is widely used in industrial automation and high-speed data acquisition systems.
