TRICONEX 2000418 safety applications for process control

The Triconex 2000418 is part of the Triconex Safety Instrumented System (SIS) product line, which is now under Schneider Electric’s EcoStruxure™ Triconex brand. This module is typically used in critical safety applications for process control in industries like oil & gas, petrochemical, and power generation.

Technical Parameters of Triconex 2000418:

1. Type:

• Likely a Triconex Input/Output (I/O) module or communication module, though exact function depends on the specific model variant.
• Common variants include analog input, digital input, or relay output modules.

2. Compatibility:

• Designed for Triconex Tricon or Trident safety systems.
• Works with Tricon v9, v10, or v11 systems (depending on firmware).

3.Input/Output Specifications (if applicable):

• Digital Input:

• • Voltage range: Typically 24V DC (sourcing/sinking configurable).
  • Isolation: High-voltage isolation for safety.
• Analog Input:

• • May support 4-20mA, 0-10V, or thermocouple/RTD signals (if applicable).
• Relay Output:

• • Contact rating: 5A @ 230V AC/30V DC (typical for safety relays).

4. Communication Protocol:

• Supports TriStation™ (Triconex engineering software) for configuration.
• May include Modbus TCP/IP or other industrial protocols (if a comms module).

5. Environmental Ratings:

• Operating Temperature: -40°C to +70°C (industrial grade).
• Certifications: ATEX, IECEx, SIL 3 (IEC 61508) for hazardous areas.

6. Redundancy & Diagnostics:

• Triple Modular Redundancy (TMR) for fault tolerance.
• Online diagnostics for module health monitoring.

7. Power Supply:

• Typically 24V DC (redundant power inputs available).

Applications:

• Emergency Shutdown Systems (ESD).
• Fire & Gas Detection Systems.
• Turbine Control.
• Burner Management.
