TRICONEX 2290614

The TRICONEX 2290614 is a communication module (also referred to as a bus interface module) used in Triconex safety systems for network communication between controllers and external systems. Below are its key technical specifications:

TRICONEX 2290614 Technical Parameters

General Information

• Manufacturer: Schneider Electric (formerly Triconex)
• Series: Tricon Communication Module
• Model: 2290614
• Type: Bus Interface / Communication Module

Communication & Networking

• Protocol Support:
  • Modbus TCP/IP (for integration with SCADA/DCS)
  • TriStation 1131 (Triconex programming software compatibility)
  • OPC (optional, depending on configuration)
• Ports:
  • Ethernet (10/100 Mbps) (for network connectivity)
  • RS-232/RS-485 serial (optional, depending on variant)
• Data Exchange:
  • Real-time data transfer between Tricon controllers and host systems
  • Supports peer-to-peer communication in redundant systems

Electrical & Environmental

• Power Supply:
  • 24V DC (typical, varies based on system requirements)
• Operating Temperature:
  • -40°C to +70°C (-40°F to +158°F)
• Humidity:
  • 5% to 95% (non-condensing)

Certifications & Safety

• Safety Standards:
  • IEC 61508 (SIL 3 capable)
  • CE, ATEX (for hazardous environments, if applicable)
• EMC Compliance:
  • IEC 61000-6 (Industrial EMC immunity & emissions)

Physical & Installation

• Mounting:
  • DIN rail or chassis-mounted (compatible with Triconex racks)
• Dimensions:
  • Approx. ~150mm x 100mm x 50mm (varies slightly by version)

Compatibility

• Works with:
  • Tricon v9, v10, v11 controllers
  • TriStation 1131 (for configuration)
• Typical Use Cases:
  • Process automation safety systems
  • Oil & gas, power plants, chemical industries
