TRICONEX 4000094-350 Safety Instrumented System

The Triconex 4000094-350 is part of the Triconex Safety Instrumented System (SIS) product line by Schneider Electric, designed for critical safety applications in industries like oil & gas, chemical, and power generation. Below are the key technical parameters for this module:

Triconex 4000094-350 Technical Parameters:

1. Model Number:

• • 4000094-350 (Typically a Triconex Analog Input Module or related safety component).

2. Function:

• • Likely an analog input module (verify exact function based on the specific variant).
  • Used for processing 4-20mA, 0-10V, or other analog signals in safety-critical systems.

3. Input Channels:

• • Typically 8 or 16 channels (depends on exact variant).
  • Supports HART communication (if applicable).

4. Signal Type:

• • Analog Input (AI) – Current (4-20mA) or Voltage (0-10V, ±10V).
  • May support thermocouple (TC) or RTD inputs (check datasheet).

5. Isolation & Safety:

• • High isolation voltage (e.g., 250V AC/DC).
  • Fault-tolerant design (TMR – Triple Modular Redundancy in some models).

6. Accuracy:

• • Typically ±0.1% of full scale (for analog inputs).

7. Communication:

• • Interfaces with Triconex controllers (e.g., Tricon, Trident) via backplane.
  • May support Modbus, OPC, or other protocols (if equipped with comms option).

8. Power Supply:

• • 24V DC (standard for Triconex systems).
  • Power consumption: ~5W (varies by model).

9. Operating Temperature:

• • -40°C to +70°C (industrial-grade range).

10. Certifications:

• • IEC 61508 (SIL 3), TÜV, ATEX, FM, CSA (depending on model).
