TRICONEX 8305A
The Triconex 8305A is a module from the Tricon v9–v11 safety instrumented system (SIS) by Schneider Electric (formerly Triconex). It is part of the Main Processor family and serves as a communication module or I/O expansion module, depending on the configuration.
Key Technical Parameters of Triconex 8305A:
1. Function:
- Acts as a communication module (e.g., for Modbus, TriStation, or other protocols) or I/O expansion module in a Tricon system.
- Supports redundant communication for high availability.
2. Compatibility:
- Works with Tricon v9, v10, and v11 systems.
- Interfaces with Tricon Main Processors (MPs) and other I/O modules.
3. Communication Protocols:
- Supports TriStation communication (for engineering and monitoring).
- May support Modbus RTU/TCP, OPC, or other industrial protocols (depending on firmware).
4. Redundancy & Fault Tolerance:
- Triple Modular Redundant (TMR) architecture for high reliability.
- Hot-swappable for maintenance without system shutdown.
5. Power Requirements:
- Typically operates on 5V DC (supplied via Tricon backplane).
- Power consumption depends on configuration (usually <10W).
6. Environmental Specifications:
- Operating Temperature: -40°C to +70°C (-40°F to +158°F).
- Humidity: 5% to 95% (non-condensing).
- Certifications: Typically ATEX, IECEx, SIL3 (IEC 61508), and TÜV-approved for safety-critical applications.
7. LED Indicators:
- Status LEDs for Power, Communication, Fault, and Redundancy status.
8. Mounting & Dimensions:
- Designed for rack mounting in a Tricon chassis.
- Standard Tricon module size (varies, but typically ~200mm x 100mm x 50mm).
Applications:
- Used in oil & gas, chemical plants, power generation, and other safety-critical industries.
- Facilitates real-time communication between Tricon controllers and SCADA/DCS systems.
Main Brand:
ABB Allen-Bradley Alstom Bently Emerson Foxboro
GE MOOG Schneider Woodward HIMA Honeywell
First hand source, affordable price. Spot inventory!
