TRICONEX DI 3506X Digital Input Module

TRICONEX DI 3506X

TRICONEX DI 3506X Digital Input Module – Technical Specifications

1.  General Information

• Manufacturer: Schneider Electric (formerly Triconex)
• Model: DI 3506X
• Module Type: High-Density Digital Input Module
• Function: 32-channel isolated digital input for safety systems
• Compatibility: Tricon v9, v10, v11 safety systems

2. Electrical Characteristics

• Input Channels: 32 (individually isolated)
• Input Type:
  • Dry Contact (Form A/Form B relays)
  • Wet Contact (24V DC)
• Input Voltage Range:
  • 24V DC (Nominal)
  • Compatible with 12-48V DC (with external conditioning)
• Input Current: ~5-10mA per channel (typical)
• Isolation:
  • Channel-to-Channel Isolation: 500V AC
  • Field-to-Backplane Isolation: 1500V AC

3. Performance & Response Time

• Response Time:
  • <10 ms (configurable debounce filter)
• Update Rate: Synchronized with Tricon scan time

4. Diagnostics & Indicators

• Per-Channel LED Indicators:
  • Green (Active)
  • Red (Fault/Error)
• Module Status LEDs:
  • Power, Communication, Fault
• Built-in Diagnostics:
  • Open wire detection
  • Short-circuit detection

5. Communication & Integration

• Backplane Interface: TMR (Triple Modular Redundant)
• Protocol: Triconex proprietary (TriStation compatible)

6. Power Requirements

• Power Supply: Backplane-powered (5V DC from Tricon chassis)
• Power Consumption: ~2W (typical)

7. Environmental Ratings

• Operating Temperature: -40°C to +70°C
• Storage Temperature: -40°C to +85°C
• Humidity: 5% to 95% (non-condensing)
• Vibration/Shock Resistance: Complies with IEC 60068-2-6/27

8. Safety & Certifications

• Safety Standards:
  • IEC 61508 (SIL 3 Certified)
  • TÜV Rheinland Approved
• Industrial Certifications:
  • ATEX / IECEx (for hazardous areas)
  • CE, UL, CSA

9. Mechanical Specifications

• Dimensions: Standard Tricon module size (fits 9U/15U chassis)
• Weight: ~0.5 kg
• Mounting: Hot-swappable (supports online replacement)

10. Typical Applications

• Emergency Shutdown Systems (ESD)
• Fire & Gas Detection Systems (FGS)
• Turbine Control Systems
• Process Safety Monitoring
