TRICONEX DI6503

The Triconex DI6503 is a Digital Input Module designed for high-density, safety-critical applications in the Triconex Tricon Safety Instrumented System (SIS). Below are its key technical specifications:

Triconex DI6503 Technical Parameters

General Specifications:

• Manufacturer: Triconex (Schneider Electric)
• Model: DI6503
• Type: High-Density Digital Input Module
• Function: Reads 24V DC digital signals (ON/OFF states) from field devices (e.g., switches, sensors).
• Safety Integrity Level (SIL): SIL 3 (IEC 61508 / IEC 61511)
• Compatibility: Works with Tricon v9, v10, v11, and Tricon CX systems.

Input Specifications:

• Number of Channels: 32 channels (high-density)
• Input Type: 24V DC (Sink/Source)
  • Voltage Range: 15-30V DC (Nominal 24V)
  • “ON” Signal: ≥18V DC
  • “OFF” Signal: ≤5V DC
• Input Current: ~5-10 mA per channel (typical)
• Isolation: Opto-isolated (channel-to-channel & field-to-system)
• Response Time: <10 ms (configurable)

Redundancy & Diagnostics:

• Triple Modular Redundancy (TMR): Supports TMR voting when used in a Tricon system.
• Fault Detection:
  • Open/short circuit detection
  • Power supply monitoring
  • Online diagnostics via Tricon diagnostics software

Communication & Integration:

• Backplane Interface: Connects to Tricon chassis (e.g., 3008, 3009).
• Hot-Swappable: Yes (allows replacement without system shutdown).
• Configuration: Programmed via TriStation 1131 software.

Environmental & Mechanical:

• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Humidity: 5% to 95% (non-condensing)
• Mounting: Installed in Tricon baseplate (e.g., 4-slot or 8-slot chassis).
• Certifications:
  • ATEX / IECEx (for hazardous areas)
  • UL, CE, cUL, TÜV

Power Requirements:

• Supply Voltage: 5V DC (from Tricon backplane)
• Power Consumption: ~5W (varies based on active channels)

Typical Applications:

• Emergency Shutdown Systems (ESD)
• Fire & Gas Detection (F&G)
• Burner Management Systems (BMS)
• Process Interlocks in oil & gas, petrochemical, power plants.
